描述
1. Introduction:Sanayi System’s TRCX is suitable for large-area RC analysis of LCD, OLED, and touch screens. It can quickly generate various 3D structures and quickly calculate resistance and capacitance values (Resistance and Capacitance)
2. TRCX simulation concept:
Let the user import the design diagram of the entire Panel, and calculate the resistance and capacitance values in a large area. The simulation flow is as follows:
3. TRCX software features:
1. It can read resistance and capacitance information on a large area.
2. It can simulate the state of resistance and capacitance on the touch screen.
3. Data extraction of RC in the panel.
4. Simple and easy-to-use 3D structure generation mechanism, various structure generation conditions, users can easily choose different modes to generate simulated structures.
5. The latest unstructured grid structure can be used to generate the simulation speed.
6. Support distributed and parallel computing
7. Support LSF resource utilization platform
8. Variable simulation that can set various structures
Unstructured mesh generation v.s. Hierarchical structured mesh generation
Touch Screen Capacitive Simulation
Fingerprint Simulation
